ABB System Pro M Compact S200M MCB, 3P, 20A Curve C, 440V AC, 10 kA Breaking Capacity
Technical Document
Specifications
Brand
ABBNumber of Poles
3P
Current Rating
20A
Tripping Characteristics
Type C
Rated AC Voltage
440V
Breaking Capacity at Maximum Voltage Rating
10 kA
Range
System Pro M Compact
Series
S200M
Circuit Breaker Type
MCB
Width
52.5mm
Length
88mm
Mounting Style
DIN Rail Mount
Depth
69mm
Model Number
S203M-C20
Terminal Contact Type
Screw
Tripping Mechanism
Thermal
Country of Origin
Germany
Product details
Type C Triple Pole 10kA System pro M Compact
The ABB S200 Series of MCB offer a compact solution for protection requirements. These miniature circuit breakers are current limiting; DIN rail mounted and can offer a good equivalent to fused systems.
Type C characteristic offers short circuit response of 5-10 x normal rated current, making it ideal for circuits with higher inrush currents such as motor control and fluorescent lighting installations in industrial buildings where nuisance tripping might occur if a faster type was used.
DIN rail mounting
Complies with BS EN 60898
Finger Safe Terminals
