Broyce Control Phase, Voltage Monitoring Relay, 1 Phase, SPDT, DIN Rail

RS Stock No.: 850-5395Brand: Broyce ControlManufacturers Part No.: LXCVR 230V
brand-logo
View all in Monitoring Relays

Technical Document

Specifications

Brand

Broyce Control

Monitoring Application

Phase, Voltage

Electrical Phase

1

Contact Configuration

SPDT

Voltage Sensitivity

Overvoltage, Undervoltage

Mounting Type

DIN Rail

Phase Sensitivity

Single Phase

Time Delay

0.2 → 10s

Frequency Sensing Range

48 → 63Hz

Series

L

Height

89mm

Length

66.5mm

Operating Temperature Range

+60°C

Special Features

Adjustment for Trip Level & Time Delay

Number of Poles

1

Minimum Operating Temperature

-20°C

Width

17.5mm

Maximum Operating Temperature

+60°C

Dimensions

66.5 x 17.5 x 89mm

Current Range

Maximum of 8A

Terminal Type

Screw

Country of Origin

United Kingdom

Product details

L Series - Control Relays

L Series relay range of Timers, Control and Three Phase relays incorporate the latest technology and offer a wide range of user adjustable features.

17.5mm DIN rail housing
Microprocessor based
1 x SPDT relay output 8A
Green LED indication for supply status
Red LED indication for relay status

Approvals

UL Certification
