Omron 10 Way Through Hole DIP Switch, Rotary Flush Actuator
Technical Document
Specifications
Brand
OmronNumber of Positions
10
Mounting Type
Through Hole
Package Style
DIP
Actuator Type
Rotary Flush
Contact Current Rating
25 mA@ 24 V dc
Maximum Operating Temperature
+80°C
Minimum Operating Temperature
-25°C
Operating Temperature Range
-25 → +80°C
Voltage Rating
24V dc
Dielectric Strength
250V ac
Country of Origin
China
Product details
DIP Sealed Rotary Switches (IP60)
A range of low cost PCB mount rotary DIP switches. Series includes top or side actuator with flat or spindle shaft models.
Rotor has an O-ring sealed construction that prevents the ingress of dirt and dust (IP60)
RoHS compliant
10 or 16 way switching positions
Contact rating: 25mA @ 24Vdc
Contact resistance: 200mΩ max
Insulation resistance: 100MΩ min @ 250Vdc
Electrical life: 5000 steps per min
Operating temperature: -25 to +80°C
2.54mm pin spacing
PCB Mounting
